Ji kerr computer controller series
Home > Product center > Ji kerr computer controller series
Product center > Ji kerr computer controller series
Variable pump controller
Product performance：
● The controller has flexible operation and efficient user guide interface.
● Multi-stroke filling mode, time filling mode, production point filling mode, standby anti-lock mode.
●Standard I/O communication interface, can be used independently or easy to communicate with PLC or industrial computer.
●Fill the liquid according to the set parameters, and automatically stop filling when the specified amount of liquid is reached.
● Adopt programmable controller and touch screen parameter setting.
●The parameters can be set to forward L/ backward R mode, liquid injection amount, motor speed, etc.
● Capacity count.
●It has the function of feedback signal output such as running time, after completion and fault alarm.
● Available for OEM.
Telephone：0769-83328418
Message feedbackPrevious：Conventional injection pump control series
Next：no more
Detailed introduction
Product performance：
● The controller has flexible operation and efficient user guide interface.
● Multi-stroke filling mode, time filling mode, production point filling mode, standby anti-lock mode.
●Standard I/O communication interface, can be used independently or easy to communicate with PLC or industrial computer.
●Fill the liquid according to the set parameters, and automatically stop filling when the specified amount of liquid is reached.
● Adopt programmable controller and touch screen parameter setting.
●The parameters can be set to forward L/ backward R mode, liquid injection amount, motor speed, etc.
● Capacity count.
●It has the function of feedback signal output such as running time, after completion and fault alarm.
● Available for OEM.
Specification and model |
JKR-BLQ-1 | JKR-BLQ-2 |
Number of pumps that can be carried | 1 | 2 |
Total trigger port | 1 | 1 |
Independent trigger port | 1 | 2 |
Feedback output port | 1 | 2 |
RS232 port | 1 | 1 |
Configure power supply | AC220V/50Hz | AC220V/50Hz |
power | 350W | 350W |
Overall dimension | 295×215×155mm | 295×215×155mm |
weight |
